Pro Compare

Specification

Trail
Model 8.0 6259.0 625
Price EU: €4499 (Online only) EU: €5199 (Online only)
Frame Material Carbon/AluminiumCarbon/Aluminium
Weight 23.9kg23.5kg
Adjustable Geometry
Motor Bosch Performance CX Gen 4 (85Nm)Bosch Performance CX Gen 4 (85Nm)
Battery Bosch PowerTube 625 (625Wh)Bosch PowerTube 625 (625Wh)
Quick Release Battery
Display Bosch PurionBosch Kiox
Front Fork Fox 36 RhythmFox 36 Performance
Rear Shock Fox Float X PerformanceFox Float X Performance
Suspension Travel F: 160mm R: 140mm F: 160mm R: 140mm
Seatpost Radon Competition Dropper (L: 150mm travel) Radon Competition Dropper (L: 150mm travel)
Brakes Magura MT Trail Shimano XT
Rear Derailleur Shimano XT Shimano XT
Cassette Shimano M6100 12 speed Shimano M8100 12 speed
Wheel Size F: 29" R: 29" F: 29" R: 29"
Tyres F: Maxxis Minion DHF R: Maxxis Minion DHR II F: Maxxis Minion DHF R: Maxxis Minion DHR II

* Estimated price based on unofficial sources.

Geometry

Frame Geometry Layout
Frame size L
Geometry Setting
R Reach 456mm
SH Stack Height 629mm
SL Seattube Length 455mm
WB Wheelbase 1244mm
CL Chainstay Length 459mm
BB Height
SA Seattube Angle 75.1°
SO Standover Height 781mm
HA Headtube Angle 65.1°

Specification and geometry values are based on European market bikes. Every attempt is made to ensure the data is correct, but differences may occur in some regions for sales or availability reasons. Please check the bike manufacturer's specification sheet before buying a bike to ensure you're getting the bike specification you want.
