2022 Orbea Rise H H15
2022 Orbea Rise H H30
On this sub-20kg bike, you definitely almost feel like you're riding a full powered e-bike.
| Check the prices in your region | |
|---|---|
| North America | Buy at Jenson USA |
| United Kingdom | Buy at Leisure Lakes Bikes UK |
Specification
Trail
| Model | H30 | H15 | H10 |
|---|---|---|---|
| Price | No longer for sale | No longer for sale | No longer for sale |
| Frame Material | Aluminium | Aluminium | Aluminium |
| Weight | 20.8kg | ||
| Adjustable Geometry | |||
| Motor | Shimano EP8-RS (60Nm) | Shimano EP8-RS (60Nm) | Shimano EP8-RS (60Nm) |
| Battery | Orbea RS Internal 540 (540Wh) | Orbea RS Internal 540 (540Wh) | Orbea RS Internal 540 (540Wh) |
| Quick Release Battery | |||
| Display | Shimano SC-E7000 | Shimano SC-E7000 | Shimano EW-EN100 |
| Front Fork | Marzocchi Bomber Z2 | Fox 36 Float Performance | Fox 34 Float Factory |
| Rear Shock | Fox Float DPS Performance | Fox Float X Performance | Fox Float DPS Factory |
| Suspension Travel | F: 140mm R: 140mm | F: 150mm R: 140mm | F: 150mm R: 140mm |
| Seatpost | OC MC20 Mountain Control Dropper | OC MC20 Mountain Control Dropper | OC MC20 Mountain Control Dropper |
| Brakes | Shimano MT410 | Shimano M6100 | Shimano XT |
| Rear Derailleur | Shimano SLX | Shimano XT | Shimano XT |
| Cassette | Shimano M7100 12 speed | Shimano M7100 12 speed | Shimano M8100 12 speed |
| Wheel Size | F: 29" R: 29" | F: 29" R: 29" | F: 29" R: 29" |
| Tyres | F: Maxxis Dissector R: Maxxis Rekon | F: Maxxis Dissector R: Maxxis Rekon | F: Maxxis Dissector R: Maxxis Rekon |
| Available with 252Wh Range Extender | Available with 252Wh Range Extender | Available with 252Wh Range Extender |
* Estimated price based on unofficial sources.
Geometry
| Frame size | L | L |
|---|---|---|
| Geometry Setting | 140mm Fork | 150mm Fork |
| R Reach | 474mm | 474mm |
| SH Stack Height | ||
| SL Seattube Length | 457mm | 457mm |
| WB Wheelbase | 1229mm | 1229mm |
| CL Chainstay Length | 445mm | 445mm |
| BB Height | 32mm | |
| SA Seattube Angle | 77.0° | 76.5° |
| SO Standover Height | 766mm | 766mm |
| HA Headtube Angle | 66.0° | 65.5° |
Specification and geometry values are based on European market bikes. Every attempt is made to ensure the data is correct, but differences may occur in some regions for sales or availability reasons. Please check the bike manufacturer's specification sheet before buying a bike to ensure you're getting the bike specification you want.
